Product Summary

The TL084QD JFET-input operational amplifier is designed to offer a wider selection than any previously developed operational amplifier family.

Parametrics

Absolute maximum ratings: (1)Supply voltage, VCC+: 18 V; (2)Supply voltage VCC–: -18 V; (3)Differential input voltage, VID: ± 30 V; (4)Input voltage, VI: ±15 V; (5)Duration of output short circuit: unlimited; (6)Operating free-air temperature range, TA: -40 to 125 ℃; (7)Storage temperature range, Tstg: -65 to 150 ℃; (8)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260 ℃.

Features

Features: (1)Low Power Consumption; (2)Wide Common-Mode and Differential Voltage Ranges; (3)Low Input Bias and Offset Currents; (4)Output Short-Circuit Protection; (5)Low Total Harmonic Distortion: 0.003% Typ.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TL084QD
TL084QD
Texas Instruments
Operational Amplifiers - Op Amps Quad Gen Pur
Data Sheet
0-650: $0.24
650-1000: $0.23
1000-2000: $0.21
2000-5000: $0.20
TL084QDR
TL084QDR
Texas Instruments
Operational Amplifiers - Op Amps Quad JFET Input
Data Sheet
0-1900: $0.19
1900-2000: $0.19
2000-2500: $0.19
2500-5000: $0.18
TL084QDRG4
TL084QDRG4
Texas Instruments
Operational Amplifiers - Op Amps JFET-Input Op Amp
Data Sheet
0-1900: $0.19
1900-2000: $0.19
2000-2500: $0.19
2500-5000: $0.18
TL084QDG4
TL084QDG4
Texas Instruments
Operational Amplifiers - Op Amps JFET-Input Op Amp
Data Sheet
0-1: $0.49
1-25: $0.39
25-100: $0.35
100-250: $0.22
